Google Pay™ lets your customers pay quickly and securely using the cards saved to their Google Account. As their Payment Service Provider, HiPay decrypts the Google token and processes the payment on your behalf.

We support Google Pay on both Web and Android.

Mandatory before going live

Every merchant must comply with the official Google Pay API Terms of Service and Acceptable Use Policy before processing live transactions. This applies to every integration method, Web and Android alike.

Choose your integration path

The two paths are independent and share nothing: pick the one that matches the surface your customers buy from. A merchant selling on both runs both.

Web

Websites and web applications

Google Pay is displayed directly on your checkout page. This documentation, together with Google's integration checklist, is enough to start accepting payments on your site.

You can either build your own integration against the Google Pay API, or use the HiPay JS SDK, which handles eligibility, the payment sheet and tokenization for you. See the dedicated section further down this page.

Android

Native Android applications

Google Pay is integrated inside your mobile app through Google's Android API. HiPay stays the Payment Service Provider: your app obtains the Google token, your server sends it to HiPay.

Follow Google's official guide, then run through the integration checklist and the brand guidelines before submitting your app.

Integration via HiPay SDK JS

Direct Integration (No SDK)

Integration via HiPay SDK JS

HiPay JS SDK · Google Pay · Integration guide

Show the Google Pay button on your checkout page and let HiPay handle eligibility, the payment sheet, and the exchange of the Google token for a HiPay token. In about forty lines of front-end code.

How it works

You put an empty <div> on your page. The SDK injects a HiPay iframe into it, and that iframe holds the real Google Pay button. Everything that touches the card stays inside the iframe: your page never sees card data.

Your page calls create()

The SDK validates your options, creates the iframe, and checks with HiPay that the card networks you asked for are actually enabled on your account.

The iframe asks Google whether the buyer can pay

If so, the official button appears and you receive ready. If not, you receive unavailable, the slot collapses, and you hide your block.

The buyer clicks and the Google Pay sheet opens

They pick a card and confirm. Google returns an encrypted token, which the iframe immediately exchanges for a HiPay token with the HiPay secure vault — while the sheet is still open.

You receive the HiPay token

The paymentAuthorized event hands you the token and its context data. Your server uses it to create the transaction through the Order API.

Key point

A HiPay token is not a payment. Until your server calls the Order API with that token, nothing is charged. The token is single-use and short-lived: send it to your server as soon as you receive it.

Requirements

Item	Detail
HiPay account	Google Pay must be enabled on your merchant account. The card networks allowed on the account are checked every time the button is displayed.
API credentials	The SDK needs both a `username` and a `password`. The merchant identifier sent to Google is derived from them: an `auth_token` alone is not enough for a wallet element.
HTTPS	Google Pay refuses to load outside HTTPS, including in the test environment.

Security

The credentials you put on this page are readable by anyone. Use the API account dedicated to the front end (Hosted Fields), never the credentials of the server account that calls the Order API.

STEP 1

Load the SDK

A single <script> tag, before your own code.

index.html

<!-- Test -->
<script src="https://stage-libs.hipay.com/js/sdkjs.js"></script>

<!-- Production -->
<script src="https://libs.hipay.com/js/sdkjs.js"></script>

Note

The Google Pay script (pay.google.com/gp/p/js/pay.js) is loaded by HiPay inside the iframe. Do not add it to your own page.

STEP 2

Prepare the container

This is the step that costs the most integration time. Three rules, and the button shows up on the first try.

index.html

<div id="hipay-googlepay"></div>

style.css

#hipay-googlepay {
  width: 100%;
  max-width: 320px;
  height: 48px;  /* an explicit height, not "auto" */
}

Rule 1 — selector is an id, not a CSS selector

Pass "hipay-googlepay", not "#hipay-googlepay" and not ".my-block". The SDK looks the element up by its id. Any other form gives you SELECTOR_NOT_FOUND.

Rule 2 — the container must be empty

No child element, no text, not even a non-breaking space or a templating comment that renders text. The SDK refuses to populate a container that is already occupied and throws SELECTOR_CONTAINER_NOT_EMPTY. Your own loader therefore belongs next to the container, not inside it.

Rule 3 — the container must have a resolvable height

The iframe is laid out as width: 100%; height: 100%. If its parent is height: auto, the percentage cannot resolve and the browser falls back to an iframe’s intrinsic size: 300 × 150 px. Give it a height in pixels, as a percentage of a parent that is itself sized, or through a grid / flex track.

Minimum size

The iframe enforces a floor of 240 × 40 px, Google’s documented minimum for the button. A narrower container is overflowed and the button label is clipped, silently.

STEP 3

Create the HiPay instance

checkout.js

const hipay = new HiPay({
  username: '01234567.stage-secure-gateway.hipay-tpp.com',
  password: 'Test_xxxxxxxxxxxxxxxxxxxxxxxx',
  environment: 'stage',        // 'stage' | 'production'
  lang: 'en',
  debug: false
});

Option	Required	Purpose
username	yes	API username. Also used to derive the merchant identifier sent to Google.
password	yes	API password.
lang	no	SDK language. Defaults to `fr`. No effect on Google Pay, which displays no HiPay text to the buyer.
environment	no	`stage`, `production` or `custom`. Defaults to `production`. Only `production` puts Google Pay in PRODUCTION mode; anything else stays in TEST.
debug	no	`true` turns on `[HiPay:*]` console traces, both on your page and inside the iframe.
custom_urls	no	Routes calls to your own endpoints. Relevant keys here: `gateway`, `secure_vault`.

Watch out

As long as environment is anything other than production, Google Pay runs in the test environment: the cards shown are test cards and no real payment is possible. This is the single most common cause of “it worked in staging” tickets.

STEP 4

Create the wallet element

checkout.js

let wallet;

try {
  wallet = hipay.create('wallet', {
    selector: 'hipay-googlepay',
    provider: 'googlepay',
    displayName: 'My Store',
    request: {
      amount: '42.90',
      currencyCode: 'EUR',
      countryCode: 'FR',
      supportedNetworks: ['visa', 'mastercard']
    }
  });
} catch (error) {
  // error.code: stable code, worth logging and quoting to support.
  // error.message: the detail, with the path of the offending field for an option.
  console.error(error.code, error.message, error.details);
}

create() is synchronous

It does not return a promise: it throws when something is wrong, invalid options included, since schema validation throws too. The try / catch is not optional: at that moment the instance does not exist yet, so there is no on('error') to listen on. Throwing is the only channel available for a creation failure.

And the most common failure is not a typo, it is context: SELECTOR_NOT_FOUND when the container has not been rendered yet. Without a catch, the exception breaks everything after it in your script, including your other payment methods.

What the thrown error carries

The thrown object carries code, message, details and payload. code is the value to test if you want to tell cases apart; message gives, for an invalid option, the exact path of the offending field.

{
  "name": "HIPAY_INTERNAL_ERROR",
  "code": "CREATE_OPTIONS_INVALID_TYPE",
  "message": "options.request.amount: expected string, received number",
  "details": {}
}

One exception: the legacy SDK

The checks on the constructor and on create()‘s arguments run before the v2 part and throw an Error without a code: the code is then the value of message (HIPAY_CREATE_MISSING_TYPE…). See table A3.

The schema is strict

Any unknown key in options or in request makes create() fail, with Unrecognized key in originalError.message. This is deliberate: a typo on currencyCode is better than a payment started in the wrong currency.

The amount is a string

amount: '42.90', not 42.9. The number of decimals must match the currency: two for EUR, none for JPY. A value that is too precise is rejected, a value that is too short is padded ('42' becomes '42.00' in euros). Minimum: 0.01.

The full list of options is in the reference.

STEP 5

Listen to events

Seven events. Two tell you what occupies your slot, three concern the outcome of the payment, two report failures.

checkout.js

// — Display verdict: exactly one of the two arrives. —

// 1. The button is displayed and clickable.
wallet.on('ready', () => {
  hideYourLoader();
});

// 2. Nothing to show for this buyer. The iframe removes itself;
//    what happens to the rest of your page is up to you.
wallet.on('unavailable', ({ code }) => {
  console.info('Google Pay unavailable:', code);
});

// — Payment outcome, after the buyer clicks. —

// 3. The payment is authorized.
//    Send this whole payload to your backend: it is the one, and the only one,
//    that calls the HiPay Order API to create and capture the transaction.
wallet.on('paymentAuthorized', (paymentData) => {
  sendToBackend(paymentData);
});

// 4. The buyer closed the sheet. This is not an error.
wallet.on('paymentCanceled', () => {
  showMessage('Payment canceled.');
});

// 5. The payment did not go through. The button stays clickable.
wallet.on('paymentFailed', (failure) => {
  console.warn(failure.code, failure.details);
  showMessage('The payment failed. Please try another payment method.');
});

// — Diagnostics. —

// 6. Non-blocking degradation: the flow carries on.
wallet.on('warning', (warning) => {
  monitoring.capture(warning.code, warning);
});

// 7. Technical failure. For your monitoring, not for the buyer.
wallet.on('error', (error) => {
  monitoring.capture(error.code, error);
});

Telling cases apart

If you want to react differently depending on the situation — hide the block, offer another payment method, show a particular message — use the code field of the payload. The other fields (message, details) are there for diagnostics and monitoring.

Four events carry a code: unavailable, paymentFailed, error and warning — in other words everything that can go sideways, an ineligible buyer included. The other three do not: ready and paymentCanceled have no payload at all, and paymentAuthorized carries payment data, not a code. There is only one way to succeed.

What paymentData contains

The payload is more than the token: it also carries the card brand, the payment product to declare, and three blocks of context the Order API expects. Send it whole, without picking pieces out of it.

{
  "token": "faf3f4a8ff5e6d0541e0c8a9b9a4a3f1",   // HiPay card token, single-use
  "brand": "VISA",                                // brand returned by the vault
  "payment_product": "visa",                    // payment product to declare
  "provider": "googlepay",
  "browser_info": { … },                       // browser block for 3-D Secure v2
  "device_fingerprint": "04000QZ7h9…",          // optional
  "data_id": "8f2c1e40-…"                      // optional
}

The detail of browser_info and the role of each field are in the payload reference; the mapping to the Order API is in step 6.

STEP 6

Capture on your server

Capture happens from your server, never from the browser. Your page forwards the paymentAuthorized payload as is to your backend; your backend calls the HiPay Order API with that token and the order details. Here is what each field is for.

Payload field	Use on the Order API side
token	The HiPay card token, single-use.
payment_product	The payment product to declare (`visa`, `mastercard`, `cb`…).
brand	The card brand as returned by the vault. Informational.
provider	`googlepay`. Useful for your own logging.
browser_info	Browser block expected by 3-D Secure v2 authentication.
device_fingerprint	Device fingerprint, for fraud prevention.
data_id	HiPay analytics session identifier.

The rest is yours

Amount, currency, order reference, description, customer details: your server supplies them, from your own cart — never from values passed through the browser. See the Order API documentation for the full list of fields.

Never do this

Do not log the token and do not store it. Do not use the amount returned by the browser to build the transaction: a customer can change it.

Full example

A minimal page showing how the previous steps fit together, in two files as in a real integration. It is an illustration, not an integration starting point: adapt it to your page, your error handling and your constraints before going live.

checkout.html

<!doctype html>
<html lang="en">
<head>
  <meta charset="utf-8">
  <title>Checkout</title>
  <link rel="stylesheet" href="checkout.css">
</head>
<body>
  <h1>Your order: €42.90</h1>

  <!-- Empty container with an explicit height (see checkout.css) -->
  <div id="hipay-googlepay"></div>
  <p id="message" role="status"></p>

  <!-- The SDK first, your code second -->
  <script src="https://stage-libs.hipay.com/js/sdkjs.js"></script>
  <script src="checkout.js"></script>
</body>
</html>

checkout.css

#hipay-googlepay {
  width: 100%;
  max-width: 320px;
  height: 48px;
}

checkout.js

const message = document.getElementById('message');

const hipay = new HiPay({
  username: 'YOUR_USERNAME',
  password: 'YOUR_PASSWORD',
  environment: 'stage',   // 'production' in production
  debug: true            // set back to false in production
});

let wallet;

try {
  wallet = hipay.create('wallet', {
    selector: 'hipay-googlepay',
    provider: 'googlepay',
    displayName: 'My Store',
    request: {
      amount: '42.90',
      currencyCode: 'EUR',
      countryCode: 'FR',
      supportedNetworks: ['visa', 'mastercard']
    }
  });
} catch (error) {
  console.error('[GooglePay] create failed', error.code, error.message);
}

if (wallet) {
  wallet.on('ready', () => {
    console.info('[GooglePay] button ready');
  });

  wallet.on('unavailable', ({ code }) => {
    console.info('[GooglePay] unavailable', code);
  });

  wallet.on('paymentAuthorized', (paymentData) => {
    message.textContent = 'Processing payment…';
    // Send the whole payload to your backend, which will call
    // the HiPay Order API to create and capture the transaction.
    sendToBackend(paymentData);
  });

  wallet.on('paymentCanceled', () => {
    message.textContent = 'Payment canceled.';
  });

  wallet.on('paymentFailed', (failure) => {
    console.warn('[GooglePay] failed', failure.code, failure.details);
    message.textContent = 'The payment failed. Please try another card.';
  });

  wallet.on('warning', (warning) => {
    console.warn('[GooglePay] warning', warning.code);
  });

  wallet.on('error', (error) => {
    console.error('[GooglePay] error', error.code, error);
  });
}

Before reusing this code

environment: 'stage' and debug: true are staging values. sendToBackend is yours to write: it is what forwards the payload to your server. The handlers here only log — what you show the buyer, and what happens to your page, is up to you.

Verdict guarantee

This is the most useful contract the SDK offers, and the one that saves you from writing your own timer. Three guarantees, within a bounded time after a successful create().

ready or unavailable, never both

Exactly one of the two arrives, once, per element. That is the display verdict: it states what occupies your slot.

An error before the verdict means ready will not come

But error is not itself a verdict: it does not say what occupies the slot. Depending on the failure, the slot ends up either empty, or filled with an error message rendered inside the iframe.

warning never prevents ready

The flow carries on in degraded mode. Log it, hide nothing.

How to wire your loader

Stop it on the first of ready, unavailable or error, without reading a single code. Only the first two tell you what to display.

What is not promised

An unavailable may still follow an error (the slot collapsed), and an error may follow ready (a failure during payment). Neither changes the decision your loader has already made.

Lifecycle

What happens between create() and the token, and what you can receive at each stage.

Validation and iframe creation synchronous

Options are validated, the container is checked, the iframe is injected. Any failure here is an exception thrown by create(), not an event: nothing is injected into your page.

CREATE_OPTIONS_INVALID_* SELECTOR_NOT_FOUND SELECTOR_CONTAINER_NOT_EMPTY WALLET_REQUESTED_NETWORKS_UNSUPPORTED

Iframe loading

The iframe loads and signals that it is operational — a matter of moments on a normal connection. The 15 seconds are not a waiting time but a give-up threshold: if nothing arrives before then, loading has failed. The element is torn down and no verdict follows.

error · FRAME_HANDSHAKE_TIMEOUT

Card network resolution

The SDK asks HiPay which networks are active on your account and intersects the result with your supportedNetworks. Empty intersection: the element becomes unavailable. If the call fails, your networks are kept and you receive a warning — the flow carries on, Google will revalidate anyway.

unavailable · NO_ELIGIBLE_NETWORK warning · NETWORK_RESOLUTION_FAILED

Google eligibility verdict

The iframe asks Google whether this buyer, in this browser, can pay. Positive answer: the button appears and ready fires. Negative answer: unavailable. Google usually answers in a fraction of a second; the 10 seconds are, again, a give-up threshold, beyond which the absence of an answer is treated as a failure, followed by an unavailable.

ready unavailable · GOOGLEPAY_NOT_AVAILABLE unavailable · GOOGLEPAY_NO_ACTIVE_CARD error · WALLET_ELIGIBILITY_CHECK_FAILED error · THIRD_PARTY_SDK_UNAVAILABLE

Click, payment sheet, tokenization

The buyer confirms in the Google sheet. The Google token is exchanged for a HiPay token before the sheet closes: if the exchange fails, the sheet stays open and the buyer can try again. One payment at a time: clicks made while a payment is in flight are ignored.

paymentAuthorized paymentCanceled paymentFailed · WALLET_PAYMENT_REFUSED paymentFailed · WALLET_TOKENIZATION_FAILED error · WALLET_PAYMENT_REQUEST_FAILED

Options for `create('wallet', …)`

Root

Option	Type	Required	Description
selector	string	yes	The container’s `id`, without `#`. The container must exist and be empty.
provider	string	yes	Only value accepted today: `'googlepay'`.
request	object	yes	Transaction details. See the next table.
displayName	string	no	Your store name, passed to Google Pay for the payment sheet. Without a value, the SDK sends `Demo Merchant` in the test environment, and nothing at all in production — the buyer then sees the name attached to HiPay’s Google account. Set this field so they see yours.
existingPaymentMethodRequired	boolean	no	Defaults to `false`. When `true`, the button is shown only if Google confirms the buyer already has a saved card. See the warning below.

request

Field	Type	Required	Description
amount	string	yes	Decimal as a string, minimum `'0.01'`. The number of decimals must be compatible with the currency; the value is normalized (`'42'` → `'42.00'` in EUR).
currencyCode	string	yes	ISO 4217, three uppercase letters. Example: `'EUR'`.
countryCode	string	yes	ISO 3166-1 alpha-2, two uppercase letters. The merchant’s country. Example: `'FR'`.
supportedNetworks	string[]	no	Defaults to `['visa','mastercard','maestro','cb']`. Accepted values: `visa`, `mastercard`, `maestro`, `cb` — case-insensitive, duplicates removed. Google Pay keeps only `visa` and `mastercard`; if your list contains neither, `create()` fails.

existingPaymentMethodRequired

Google is not always able to answer this question: in a cross-origin iframe, when third-party cookies are blocked — Safari’s default — it simply omits the information. The SDK treats that absence as a yes and shows the button; only an explicit refusal hides it. In the test environment Google always answers “card present”, so this option cannot be tested in staging.

Instance API

create() returns an object with three methods. Nothing else is exposed.

Method	Effect
on(event, callback)	Subscribes a listener. Several listeners per event are allowed.
removeListener(event, callback)	Removes a listener. Pass exactly the same function reference.
destroy()	Removes the iframe from the DOM, cuts communication and returns `null`. Call it when you leave the checkout page. No effect if the element has already been torn down: calling it twice, or after `unavailable`, does not throw.

Events

Event	Payload	Iframe removed	When
ready	none	no	The element is displayed and usable: the button exists and is clickable. Terminal display verdict.
unavailable	{ code }	yes	Nothing to show for this buyer or this configuration. Not an error. Terminal display verdict.
paymentAuthorized	payment data	no	HiPay tokenization succeeded. This is the only event that gives you a usable token.
paymentCanceled	none	no	The buyer closed the payment sheet. This is not an error, do not present it as one.
paymentFailed	{ code, details?, originalError? }	no	The attempt did not go through: refused by Google, or HiPay tokenization failed. The button stays clickable.
warning	error object	no	Non-blocking degradation: the flow carries on and `ready` remains possible. Log it, show nothing.
error	error object	varies	Technical failure, at bootstrap or during payment. Meant for your monitoring, not for the buyer.

“Iframe removed” does not mean “instance destroyed”

On unavailable, the SDK removes the iframe from the DOM, cuts communication with it and clears its timers. The object returned by create() stays valid: your listeners are not removed, on() and removeListener() keep working, and destroy() is still safe to call — it simply does nothing. There is nothing for you to clean up.

Payload formats

paymentAuthorized

{
  "token": "faf3f4a8ff5e6d0541e0c8a9b9a4a3f1",
  "brand": "VISA",
  "payment_product": "visa",
  "provider": "googlepay",
  "browser_info": {
    "java_enabled": false,
    "javascript_enabled": true,
    "language": "en-GB",
    "color_depth": 24,
    "screen_height": 1080,
    "screen_width": 1920,
    "timezone": "-60",
    "http_user_agent": "Mozilla/5.0 (Macintosh; …)",
    "ipaddr": "",
    "http_accept": ""
  },
  "device_fingerprint": "04000QZ7h9…",
  "data_id": "8f2c1e40-…"
}

ipaddr and http_accept are intentionally empty: the HiPay gateway fills them server-side.
device_fingerprint and data_id may be absent if they could not be resolved. Treat them as optional.
timezone is the offset in minutes, as a string, as expected by the 3-DS block.

How payment_product is determined

The HiPay vault returns a brand and, for co-badged cards, a domestic network. The domestic network wins when it is a known one.

Vault response	payment_product
domestic_network CB	cb
domestic_network BCMC	bcmc
brand VISA	visa
brand MASTERCARD	mastercard

unavailable

{ "code": "GOOGLEPAY_NOT_AVAILABLE" }

paymentFailed

code is always present; details and originalError only appear when there is something to carry.

{
  "code": "WALLET_TOKENIZATION_FAILED",
  "details": { "provider": "googlepay" },
  "originalError": {
    "name": "HttpError",
    "message": "HTTP request failed with status 500",
    "code": "HTTP_SERVER_ERROR",
    "status": 500
  }
}

originalError follows the same cause-chain structure as for error and warning: that is where you find the detail of what Google or the HiPay vault answered.

error and warning

Both share the same shape.

{
  "name": "HIPAY_INTERNAL_ERROR",
  "code": "WALLET_ELIGIBILITY_CHECK_FAILED",
  "message": "The wallet eligibility check did not answer.",
  "details": { "provider": "googlepay" },
  "originalError": {
    "name": "Error",
    "message": "WALLET_ELIGIBILITY_CHECK_TIMED_OUT"
  }
}

code identifies the step that failed. It is the value to test if you want to tell cases apart, and the one to quote in a support ticket.
name is the error type; today always HIPAY_INTERNAL_ERROR.
originalError is a recursive, stack-free cause chain — { name, message, code?, status?, details?, originalError? }. The step’s code wins at the first level, the cause descends.
details is best-effort context, never sensitive data.

Example of a cause chain

A failed gateway call, reported as a warning:

{
  "name": "HIPAY_INTERNAL_ERROR",
  "code": "NETWORK_RESOLUTION_FAILED",
  "message": "The available payment products could not be resolved.",
  "details": { "requestedNetworks": ["visa", "mastercard"] },
  "originalError": {
    "name": "HttpError",
    "message": "HTTP request failed with status 503",
    "code": "HTTP_SERVER_ERROR",
    "status": 503
  }
}

Error catalog

Every failure carries a code, the only stable discriminant. Tables are grouped by how the code reaches you.

Filter

A1 — Exceptions thrown by create()

Synchronous. Nothing is injected into your page. The code is on error.code.

error.code	Cause and fix
SELECTOR_NOT_FOUND	No element carries that `id`. Check that you are not passing `#`, and that `create()` runs after the container is rendered. `details: { selector }`.
SELECTOR_CONTAINER_NOT_EMPTY	The container already holds an element or text. Empty it, or put your content next to it. `details: { selector }`.
WALLET_REQUESTED_NETWORKS_UNSUPPORTED	Your `supportedNetworks` shares no network with Google Pay’s (`visa`, `mastercard`). `details: { requestedNetworks }`.
WALLET_USERNAME_MISSING	Wallet element with a `client` that has no `username`: the merchant identifier sent to Google is derived from it.
WALLET_PROVIDER_UNKNOWN	Internal guard on the provider dispatch. An unknown `provider` is rejected earlier by validation.
FRAME_PARAMS_INVALID	Internal guard on the iframe URL builder. Not reachable from your options.
UNEXPECTED_ERROR	Catch-all. Any occurrence is a bug worth reporting, along with `originalError`.

A2 — Invalid options

Also thrown by create(). The code follows the CREATE_OPTIONS_INVALID_<ISSUE> grammar, and message carries the path of the offending field (options.request.amount: …).

error.code	Typical trigger
CREATE_OPTIONS_INVALID_TYPE	`amount` passed as a number instead of a string.
CREATE_OPTIONS_INVALID_FORMAT	Malformed `currencyCode`, `countryCode`, `locale` or `amount`.
CREATE_OPTIONS_INVALID_VALUE	Value outside the allowed set, an unknown network for instance.
CREATE_OPTIONS_INVALID_UNION	Unknown `provider`: no schema variant matches.
CREATE_OPTIONS_INVALID_TOO_SMALL	Empty `selector`, `supportedNetworks: []`, `amount` below `0.01`.
CREATE_OPTIONS_INVALID_TOO_BIG	An address field that is too long.
CREATE_OPTIONS_INVALID_CUSTOM	Business rule: `amount` with too many decimals for the currency.
CREATE_OPTIONS_INVALID_UNRECOGNIZED_KEYS	Unknown key in `options` or `request`. Check the spelling.
CREATE_OPTIONS_INVALID_KEY	Invalid key in an options dictionary.
CREATE_OPTIONS_INVALID_ELEMENT	Invalid item in a list.
CLIENT_CREDENTIALS_MISSING	Neither `auth_token`, nor the `username` + `password` pair.
CLIENT_ENVIRONMENT_INVALID	`environment` outside `stage` / `production` / `custom`.
CLIENT_INVALID_*	Another problem on the `client` block, same grammar.
VALIDATION_ISSUE_UNKNOWN	Unmapped issue kind. Worth reporting.

A3 — Exceptions from the legacy SDK

Thrown before the v2 part is reached. These errors have no code: the code is the value of error.message.

error.message	Cause and fix
HIPAY_MISSING_INIT_OPTIONS	`new HiPay()` called without an options object.
HIPAY_MISSING_CREDENTIALS	Missing `username` or `password`. Both are required for a wallet.
HIPAY_INVALID_ENVIRONMENT	`environment` outside the allowed values.
HIPAY_CREATE_MISSING_TYPE	`create()`‘s first argument is empty or missing. Expected: `'wallet'`.
HIPAY_CREATE_MISSING_OPTIONS	`create()`‘s second argument is missing or not an object.

B — Codes of the error event

Emitted asynchronously after create(). Meant for your monitoring.

code	Cause	What follows
FRAME_HANDSHAKE_TIMEOUT	No answer from the iframe within 15 s: loading blocked by the browser, an extension, or an unreachable HiPay domain.	Element torn down. No verdict follows.
THIRD_PARTY_SDK_UNAVAILABLE	Google Pay script missing from the iframe page (`status: 'missing'`) or loaded without exposing its API (`status: 'failed'`).	The iframe displays its own message. Neither `ready` nor `unavailable`.
WALLET_PROVIDER_INIT_FAILED	Opening the Google Pay session failed.	`unavailable · ELIGIBILITY_NO_VERDICT`
WALLET_ELIGIBILITY_CHECK_FAILED	The eligibility check threw, or did not answer within 10 s. A refusal from Google is not an error.	`unavailable · ELIGIBILITY_NO_VERDICT`
WALLET_PAYMENT_REQUEST_FAILED	After `ready`: the payment sheet request failed for a technical reason, or the provider returned a blank token. A buyer cancellation emits nothing.	The button stays clickable, verdict unchanged.
FRAME_ROOT_MISSING	Build defect in the iframe page.	Nothing is rendered, no verdict.
CONTEXT_MISSING	Internal programming error inside the iframe.	Not reachable from your integration.
UNEXPECTED_ERROR	Catch-all. Any occurrence is a bug worth reporting.	Depends on the origin.

C — Codes of the warning event

Non-blocking: the flow carries on and ready remains possible.

code	Cause and consequence
NETWORK_RESOLUTION_FAILED	The gateway call listing the active payment products failed: 4xx/5xx, timeout, off-schema response. The element falls back to the networks you requested. `details: { requestedNetworks }`, HTTP cause in `originalError`.

D — Codes of the unavailable event

None of these is a failure: the button simply has no reason to be there. Hide your block and offer another payment method.

code	Meaning
GOOGLEPAY_NOT_AVAILABLE	Google states that this buyer cannot pay with Google Pay in this browser. No finer cause is given.
GOOGLEPAY_NO_ACTIVE_CARD	With `existingPaymentMethodRequired: true`, Google explicitly answered that the buyer has no saved card.
NO_ELIGIBLE_NETWORK	The intersection between the networks active on your HiPay account and your `supportedNetworks` is empty. A configuration matter, not a buyer matter.
ELIGIBILITY_NO_VERDICT	The eligibility question got no answer. The technical diagnosis arrived in parallel on `error`.

E — Codes of the paymentFailed event

code	Meaning
WALLET_PAYMENT_REFUSED	Google refused the request. What Google answered — its own code and label — travels in `originalError`.
WALLET_TOKENIZATION_FAILED	Exchanging the Google token for a HiPay token failed: vault refusal, timeout, network, unexpected response. The cause travels in `originalError`. Nothing was charged.

F — Codes that only ever appear as a cause

These are never the top-level code: you only meet them inside originalError. A test expecting one of them at the first level will never pass.

code	Appears under
GOOGLE_PAY_SDK_NOT_READY	`WALLET_PROVIDER_INIT_FAILED`
GOOGLE_PAY_SESSION_NOT_INITIALIZED	`WALLET_ELIGIBILITY_CHECK_FAILED`, `WALLET_PAYMENT_REQUEST_FAILED`
GOOGLE_PAY_PAYMENT_TOKEN_EMPTY	`WALLET_PAYMENT_REQUEST_FAILED`
HTTP_TIMEOUT	`NETWORK_RESOLUTION_FAILED` — no response within the timeout (10 s by default)
HTTP_NETWORK_ERROR	`NETWORK_RESOLUTION_FAILED` — offline, blocked, CORS
HTTP_CLIENT_ERROR	`NETWORK_RESOLUTION_FAILED` — 4xx status, `status` carried
HTTP_SERVER_ERROR	`NETWORK_RESOLUTION_FAILED` — 5xx status, `status` carried
HTTP_UNEXPECTED_STATUS	`NETWORK_RESOLUTION_FAILED` — any other non-2xx status
HTTP_RESPONSE_INVALID_*	`NETWORK_RESOLUTION_FAILED` — off-schema gateway response

Why a tokenization failure is not an error

The buyer pressed Pay and nothing was charged: that is a payment outcome, not a failure of the element. It therefore arrives on paymentFailed, your payment channel, and never on error. One rule to remember: everything that follows a click on the button arrives on the payment events.

Troubleshooting

First reflex: pass debug: true to new HiPay() and filter the console on HiPay. The HiPay:networks, HiPay:wallet and HiPay:frame channels tell you most of the story.

Symptom	Most likely cause	Fix
Nothing appears, no event, no exception	The container did not exist yet when the call ran	Call `create()` after the container is rendered. In a framework, from a mount effect.
The button is 300 × 150 px	The container is `height: auto`	Give it an explicit height. The iframe is `height: 100%` and cannot resolve otherwise.
The button label is clipped	Container narrower than 240 px	Widen the container, or leave it at `width: 100%` inside a wide enough block.
`SELECTOR_NOT_FOUND` although the `div` exists	`selector: '#my-id'` or a class selector	Pass the bare `id`, without `#`.
`SELECTOR_CONTAINER_NOT_EMPTY` on a `div` that looks empty	A space, a rendered line break, or a loading component inside it	Empty the container completely. Put any temporary content outside it.
Neither `ready` nor `unavailable` arrives	An `error` fired before the verdict	This is the only expected case. Read its `code`: `FRAME_HANDSHAKE_TIMEOUT` or `THIRD_PARTY_SDK_UNAVAILABLE` most of the time.
The button appears, but the sheet closes immediately	A parameter accepted by the eligibility check is refused by the sheet	The check is more lenient than the sheet: `ready` does not validate the transaction. Read `originalError` on `paymentFailed`.
Everything works in staging, nothing works in production	Google Pay is not enabled on your production HiPay account	The two environments have separate configurations. Contact HiPay support with the `code` you received.
The sheet shows test cards in production	`environment` is not exactly `'production'`	Only that value switches Google Pay to PRODUCTION mode.
`paymentFailed · WALLET_PAYMENT_REFUSED` as soon as the sheet opens	A transaction parameter is refused by Google	Check `countryCode`, `currencyCode` and the format of `amount`. What Google answered is in `originalError`.

Direct Integration (No SDK)

Google Pay · Direct integration · No HiPay SDK

Integrate the official Google Pay API yourself, in PAYMENT_GATEWAY mode with hipay as the gateway. You keep full control of the user experience; in exchange you own the Google Pay client, the button, the payment sheet and the token exchange.

How it works

If you would rather not use the HiPay JavaScript SDK and want to keep full control over the user experience and over the integration of the official Google Pay API on your front end, you must configure Google Pay using the PAYMENT_GATEWAY mode.

Follow the Google documentation to integrate a Google Pay solution on your website.

The exchange in one sentence

Google encrypts the buyer’s card data with HiPay’s public key. Your front end receives a secure Google token, which you convert into a HiPay token before handing it to your server, which then calls the HiPay Order API.

Prerequisites: getting your Merchant ID

Before starting the technical integration, set up your account on Google Pay & Wallet.

Step	What to do
Open the console	Go to pay.google.com/business/console.
Sign in	Create or sign in to the Google Account associated with your business.
Accept the terms	Accept the Google Pay Terms of Service and the Acceptable Use Policy.
Configure your profile	Complete your merchant profile and obtain your unique Merchant ID.
Save the ID	You will need it to configure your payment requests.

Do this first

Without this prior configuration, your integration will not work. Make sure your Merchant ID is properly configured before going any further.

The five steps

Initialize the client

Load the official Google script and instantiate the PaymentsClient in TEST or PRODUCTION mode.

Configure your parameters

Set up the official Google Pay API in PAYMENT_GATEWAY mode using hipay as the gateway.

Render the button

Verify user readiness through the API and inject the official button, respecting Google’s guidelines.

Convert the token

Retrieve the encrypted Google Pay token and convert it into a HiPay token through our secure vault API.

Process the payment

Send the HiPay token to the HiPay POST /v1/order endpoint from your server.

STEP 1

Include and initialize Google Pay

Load the official Google Pay JavaScript library on your checkout page. Load it asynchronously and instantiate the PaymentsClient as soon as the script has finished loading.

checkout.html

<script async src="https://pay.google.com/gp/p/js/pay.js" onload="onGooglePayLoaded()"></script>

Once loaded, the script automatically triggers the onGooglePayLoaded() callback. Inside that function, instantiate the PaymentsClient by declaring your target environment.

checkout.js

function onGooglePayLoaded() {
  // Instantiate the Google Pay client
  const paymentsClient = new google.payments.api.PaymentsClient({
    // ENVIRONMENT CONFIGURATION:
    // 'TEST' for development, staging and QA environments.
    // 'PRODUCTION' for your live store (requires HTTPS and an approved domain).
    environment: 'TEST'
  });

  // You can now define your configuration objects and check whether
  // the user is ready to pay. See step 2.
}

STEP 2

Configure payment and merchant parameters

Once the client is ready, define the payment configuration objects: hipay as the payment gateway, the card networks you support, and your merchant identifiers for both HiPay and Google.

checkout.js

// 1. Tokenization specification — the HiPay gateway configuration
const tokenizationSpecification = {
  type: 'PAYMENT_GATEWAY',
  parameters: {
    'gateway': 'hipay',
    // Your HiPay public API username, Base64 encoded
    'gatewayMerchantId': btoa('YOUR_PUBLIC_API_USERNAME')
  }
};

// 2. Card payment method — supported networks and authentication
const cardPaymentMethod = {
  type: 'CARD',
  parameters: {
    // HiPay supports both authentication methods
    allowedAuthMethods: ['PAN_ONLY', 'CRYPTOGRAM_3DS'],
    // Card networks supported on HiPay
    allowedCardNetworks: ['MASTERCARD', 'VISA', 'MAESTRO'],
    billingAddressRequired: true,
    billingAddressParameters: {
      // FULL includes street, city, postal code and country
      format: 'FULL',
      isPhoneNumberRequired: false
    }
  },
  tokenizationSpecification: tokenizationSpecification
};

// 3. Full Google Pay request object, carrying your merchant identity
const paymentDataRequest = {
  apiVersion: 2,
  apiVersionMinor: 0,
  allowedPaymentMethods: [cardPaymentMethod],

  merchantInfo: {
    // TEST: not validated by Google, a dummy value is accepted.
    // PRODUCTION: your official 20-digit Google Merchant ID.
    merchantId: 'YOUR_GOOGLE_MERCHANT_ID',

    // The brand name shown to the buyer in the Google Pay sheet
    merchantName: 'Your Store Name'
  },

  transactionInfo: {
    totalPriceStatus: 'FINAL',
    totalPrice: '45.00',
    currencyCode: 'EUR',      // ISO 4217
    // ISO 3166-1 alpha-2. Required if the buyer is in an SCA-regulated region.
    countryCode: 'FR'
  }
};

Two different identifiers

merchantInfo.merchantId and gatewayMerchantId are not the same thing.

merchantInfo.merchantId is your Google Merchant ID, generated by Google once your website is registered in the Google Pay Console. In TEST it can be omitted or left as a dummy value.
gatewayMerchantId is the Base64-encoded public API username of your HiPay account. It is what identifies Google Pay tokens as belonging to you.

Authentication methods

HiPay supports both Google Pay authentication methods. They differ in how the card is tokenized and in how risk is handled downstream.

	PAN_ONLY	CRYPTOGRAM_3DS
Tokenization	Google provides the standard Primary Account Number (PAN) token.	Google provides an encrypted cryptogram with device binding, instead of a PAN.
HiPay’s role	HiPay processes the transaction and may trigger 3-D Secure based on its fraud detection engine and payment risk assessment.	HiPay processes the encrypted token directly, without triggering 3-D Secure. Security is inherent to the device-based tokenization.
Use case	Standard card processing, where 3-D Secure is applied conditionally according to regulatory and risk-based requirements.	High-security transactions, where strong tokenization removes the need for an additional authentication flow.
Payment flow	token → risk assessment → possible 3-DS challenge → authorization	encrypted device-bound token → direct processing → authorization, no 3-DS page

Declaring your authentication methods

In your Google Pay request, declare the methods you accept.

checkout.js

const cardPaymentMethod = {
  type: 'CARD',
  parameters: {
    allowedAuthMethods: ['PAN_ONLY', 'CRYPTOGRAM_3DS'],
    allowedCardNetworks: ['MASTERCARD', 'VISA', 'MAESTRO']
  }
};

When you include both methods, Google Pay picks the tokenization method according to the device’s capabilities and the issuer’s support.
When you want device-based tokenization only, declare ['CRYPTOGRAM_3DS'] alone to guarantee stronger security throughout the payment chain.
The authentication_indicator parameter below controls 3-D Secure behaviour for PAN_ONLY credentials only.

Forcing 3-D Secure authentication

Control how 3-D Secure is applied to PAN_ONLY transactions with the authentication_indicator parameter of your HiPay Order request (see step 5): 1 lets HiPay’s fraud detection engine decide when 3-D Secure is needed, 2 enforces it on every transaction.

order request

{
  "authentication_indicator": 1,
  "...": "other order parameters"
}

Geographic considerations

The methods you can support depend on the transaction’s geographic context. See Google’s SCA guide for the detail.

PAN_ONLY is generally available worldwide, but HiPay may trigger 3-D Secure based on fraud detection and on the cardholder’s location.
CRYPTOGRAM_3DS is recommended in regions subject to Strong Customer Authentication, such as the EEA and the UK.

Always send countryCode

Include the right countryCode in your transaction information so that Google Pay can determine the appropriate authentication method for the local regulation.

Collecting the billing address

The billingAddressParameters configuration lets you request the buyer’s billing address during the Google Pay transaction.

checkout.js

const cardPaymentMethod = {
  type: 'CARD',
  parameters: {
    allowedAuthMethods: ['PAN_ONLY', 'CRYPTOGRAM_3DS'],
    allowedCardNetworks: ['MASTERCARD', 'VISA', 'MAESTRO'],
    billingAddressRequired: true,
    billingAddressParameters: {
      format: 'FULL',
      isPhoneNumberRequired: false
    }
  },
  tokenizationSpecification: tokenizationSpecification
};

This information is useful for:

Fraud prevention — validate the billing address against the card issuer’s records.
Order fulfilment — use the address for delivery or verification.
Compliance — hold the customer information your regulatory requirements call for.

Configuration options

Option	Value	Effect
billingAddressRequired	true	Billing address information is required. With `false`, it is optional.
format	FULL	Complete address: street, city, postal code, country.
format	FULL-ISO3166	Complete address including name, street address, locality, region, country code, postal code and ISO 3166 administrative area.
format	MIN	Minimal address: postal code and country only.
isPhoneNumberRequired	true	Also collects the buyer’s phone number along with the billing address.

The billing address returned in the Google Pay response should be passed on to HiPay in your Order request, for additional validation and fraud prevention.

STEP 3

Check readiness and render the button

Before displaying the payment button, verify that the user is able to pay with Google Pay through the isReadyToPay() method. If the answer is positive, render the official button dynamically.

Never build your own button

For Google to approve your production access, your button must strictly comply with the official Google Pay Brand Guidelines. Never create a custom HTML/CSS button from scratch: always use the button creation API provided by the script.

checkout.html

<div id="google-pay-container"></div>

checkout.js

// Check whether the user can pay with the configuration you defined
paymentsClient.isReadyToPay(paymentDataRequest)
  .then(function (response) {
    if (response.result) {
      // Create the official Google Pay button
      const button = paymentsClient.createButton({
        buttonColor: 'default',      // 'default', 'black' or 'white'
        buttonType: 'buy',           // 'buy', 'plain', 'donate', 'checkout'…
        buttonSizeMode: 'responsive',
        onClick: onGooglePayButtonClicked
      });

      // Append the button to your own container
      document.getElementById('google-pay-container').appendChild(button);
    } else {
      // Fallback: hide the Google Pay option or show your standard card form
      console.log('Google Pay is not available for this user or device.');
    }
  })
  .catch(function (err) {
    console.error('isReadyToPay error: ', err);
  });

STEP 4

Retrieve the payment token

When the buyer clicks the Google Pay button, open the Google payment sheet with loadPaymentData(). Once the buyer validates the transaction, the Google API returns a PaymentData object. Extract the raw JSON string of the encrypted token, then convert it into a HiPay token — see the HiPay token response format.

checkout.js

// Triggered when the buyer clicks your official Google Pay button
function onGooglePayButtonClicked() {

  // Open the secure Google Pay sheet
  paymentsClient.loadPaymentData(paymentDataRequest)
    .then(async function (paymentData) {

      // 1. Extract the encrypted payment token from Google's response
      const googlePayToken = paymentData.paymentMethodData.tokenizationData.token;

      // 2. Exchange the Google token for a HiPay token through the secure vault
      const response = await fetch('https://secure2-vault.hipay-tpp.com/rest/v2/google-pay/token.json', {
        method: 'POST',
        headers: {
          'Authorization': 'Basic ' + btoa('<YOUR_PUBLIC_API_USERNAME>:<YOUR_PUBLIC_API_PASSWORD>'),
          'Content-Type': 'application/json'
        },
        body: JSON.stringify({
          google_pay_token: googlePayToken
        })
      });

      const hipayTokenData = await response.json();

      // 3. Forward the HiPay token to your backend, which processes the payment
      processBackendPayment(hipayTokenData.token);

    })
    .catch(function (err) {
      // Errors, or the buyer closing the Google sheet
      console.error('Google Pay payment sheet error: ', err);
    });
}

STEP 5

Server-side processing

From your server, call our order creation endpoint POST /v1/order, injecting the token obtained in the previous step.

POST /v1/order

{
  "orderid": "CMD-2026-98765",
  "amount": 45.00,
  "currency": "EUR",
  "payment_product": "<BRAND_OR_DOMESTIC_NETWORK_OF_HIPAY_TOKEN>",
  "cardtoken": "<TOKEN_FIELD_OF_HIPAY_TOKEN>",
  "accept_url": "https://www.your-site.com/success",
  "decline_url": "https://www.your-site.com/decline"
}

Choose your integration path

How it works

Requirements

Load the SDK

Prepare the container

Create the HiPay instance

Create the wallet element

Listen to events

Capture on your server

Full example

Verdict guarantee

Lifecycle

Options for create('wallet', …)

Instance API

Events

Payload formats

Error catalog

Troubleshooting

How it works

Prerequisites: getting your Merchant ID

The five steps

Include and initialize Google Pay

Configure payment and merchant parameters

Authentication methods

Check readiness and render the button

Retrieve the payment token

Server-side processing

Options for `create('wallet', …)`
